🎮 Pixel Runner

Pixel Runner is a retro-style endless runner game built for Arduino and other microcontroller platforms. It runs on a 16×2 LCD display and is controlled using a joystick module.

The project is developed with PlatformIO and written in C++, following a modular architecture to keep the source code clean and maintainable.

✨ Features

• 🎮 Joystick controls
• 🏃 Endless runner gameplay
• ⚡ Multiple difficulty levels
• 📈 Score tracking
• 🎨 Custom LCD characters
• 🧩 Modular code structure

🛠 Hardware

• Arduino Uno R3
• 16×2 LCD (HD44780 compatible)
• Joystick Module (KY-023 or compatible)
• Jumper wires

🔌 Wiring

LCD 16×2

LCD Pin	Arduino Pin
RS	D7
E	D6
D4	D5
D5	D4
D6	D3
D7	D2
VSS	GND
VDD	5V
RW	GND
VO	10k Potentiometer (Contrast)
A (LED+)	5V (through 220Ω)
K (LED−)	GND

Joystick Module

Joystick Pin	Arduino Pin
VRx	A0
VRy	A1
VCC	5V
GND	GND

Note: If your hardware connections are different, update the pin definitions in the source code accordingly.

📁 Project Structure

include/
├── characters.h
├── constants.h
├── enum.h
├── functions.h
├── structures.h
└── variables.h

src/
├── characters.cpp
├── functions.cpp
├── main.cpp
└── variables.cpp

🚀 Getting Started

1. Clone the repository:

   git clone https://github.com/plutron/pixel-runner-Arduino.git

2. Open the project in PlatformIO.
3. Connect your Arduino Uno.
4. Build and upload the project.

🎮 How to Play

• Select the game speed.
• Move the joystick to control the player.
• Avoid incoming obstacles.
• Survive as long as possible and achieve the highest score.

🤝 Contributing

Contributions, suggestions, and bug reports are welcome. Feel free to open an issue or submit a pull request.

📄 License

This project is licensed under the MIT License.

Made with ❤️ using Arduino, PlatformIO, and C++.

Sky Machine

Bubble Operating System and Sky Machine Virtual CPU

Sky Machine is a university-level educational project simulating a virtual machine environment on Windows. This virtual machine runs a minimalist Operating System called Bubble, implemented using a unique assembly-like programming language designed specifically for this platform.

Project Overview

• The virtual machine architecture simulates memory, registers, hard disk, and CPU operation logic fully implemented in C.
• It supports a custom assembly-like language with concise syntax for programming the virtual CPU.
• This is a single-threaded virtual CPU capable of executing only one program at a time.

How It Works

1. Simulates virtual hardware components including registers and memory heaps.
2. Uses a unique low-level programming language with instructions similar to assembly for system and user-level programming.
3. Provides facilities for arithmetic, logical, control flow, I/O, and file operations in the custom language.
4. Maintains separate memory spaces for OS (Bubble) and user programs, switching execution context accordingly.

Instruction Set Overview

Instruction	Description	Example
ASSN Rn Value	Assigns a literal value to register Rn.	ASSN 1 100
MOVE Rn Addr Type	Moves data from virtual RAM address to register Rn.	MOVE 2 15 I
ASSV Rn Rm	Copies the contents from register Rm to Rn.	ASSV 1 2
COMP Rn Rm Rz	Compares if Rn < Rm, stores 1 in Rz if true.	COMP 1 2 3
EQAL Pn Pm Pz	Checks equality of registers, stores result in Pz.	EQAL 1 2 3
NEQL Pn Pm Pz	Checks inequality of registers, stores result in Pz.	NEQL 1 2 3
CJMP Pn Line	Conditional jump to line if Pn is 1 (true).	CJMP 0 100
JUMP Line	Unconditional jump to line.	JUMP 50
HALT	Terminates the running program, returns to OS.	HALT
PUTC Pn	Outputs the character stored in register Pn.	PUTC 3
PUTS Pn Pm	Outputs the string starting at address Pn.	PUTS 4 5
PUTI Pn	Outputs the integer value stored in Pn.	PUTI 6
PUSH Pn Pm Px	Stores the Pm-th index of string into Px.	PUSH 1 2 3
ADDN Pn Pm Pz	Adds values, stores result in Pz.	ADDN 1 2 3
ADDO Pn	Increments the value in Pn by 1.	ADDO 1
MULT Pn Pm Pz	Multiplies values, stores in Pz.	MULT 1 2 3
DIVI Pn Pm Pz	Divides Pn by Pm, stores quotient in Pz.	DIVI 1 2 3
MODE Pn Pm Pz	Calculates Pn mod Pm, stores remainder in Pz.	MODE 1 2 3
GETC Pn	Reads a single character input to Pn.	GETC 1
GETI Pn	Reads a single digit (0-9), stores value in Pn.	GETI 1
GETS Pn Pm	Reads a string, stores length in Pm.	GETS 1 2
ANDC Pn Pm Pz	Logical AND, stores in Pz.	ANDC 1 2 3
ORLC Pn Pm Pz	Logical OR, stores in Pz.	ORLC 1 2 3
NOTC Pn	Logical NOT of Pn.	NOTC 1

Advantages

• Educational Value: Fully coded in C, providing insight into low-level system programming and CPU simulation.
• Unique Language: Dedicated assembly-like language designed for precise control and demonstration of virtual CPU concepts.
• Single-threaded Simplicity: Focus on sequential execution helps emphasize CPU instruction processing mechanics.

Limitations

• Single-process Execution: Only one program can execute at a time on the virtual CPU.
• Early Development State: Some API features are planned but not yet implemented.
• Platform Specific: Implemented primarily for Windows.

Usage and Safety Notes

This project is intended strictly for educational and research use within controlled university or development environments. Running unverified code or modifying system settings outside isolated virtual machines is not recommended.

Team Members

• plutron
• MohammadMahdiTT
• mmdqsa438

Algo_mini_project

A mini project for TSP algorithms!

DS-FOR-NO-REASON

just for fun!!!!
